Divesoft Echo - Standard Sensor
ECHO is a gas analyzer built for technical divers who take their breathing gas seriously. Whether you're blending nitrox for a deep reef dive or mixing trimix for something more ambitious, ECHO tells you exactly what's in your cylinder, so you can focus on the dive, not the doubt.
Connect it to the Divesoft App via Bluetooth and your whole blending workflow just clicks into place, from analysis to labeled cylinder in minutes.
ECHO also checks for carbon monoxide in your breathing gas - the kind of contamination you can't see, smell, or taste, but absolutely need to know about before you descend. It's the safety check that's easy to skip and impossible to regret doing.
The helium measurement is handled by a clever acoustic sensor that never needs replacing. Less maintenance, one less thing to worry about between trips.
Light enough to toss in your dive bag without a second thought, and tough enough to survive the journey - ECHO is the kind of gear that quietly earns its place on every packing list.
The analyzer comes with the following:
- Analyzer ECHO
- Oxygen Sensor Divesoft 22S
- USB-C cable
- EVA case
Technical Specifications
Construction
Durable injection-molded reinforced plastic body.
Integrated TFT-HR display and sealed electronics designed for everyday use in dive centers, blending stations and technical diving environments.
Gas Mixes
ECHO analyzes breathing gas mixes used in diving, including nitrox and trimix.
Gases Measured
Oxygen
Helium
Sensors / Measurement Principle
Oxygen measurement using an electrochemical oxygen sensor. Helium content is determined using the speed-of-sound measurement principle.
Carbon monoxide detection uses a dedicated CO sensor.
Dimensions
Main body diameter: approx. 127 mm
Body thickness: approx. 37.5 mm
Body width: approx. 110 mm
Overall length (including strap): approx. 410 mm
Weight
255g
Oxygen Range
0–100 % O₂
Helium Range
0–100 % He
Carbon Monoxide Detection
Yes
Operating Temperature
0–40 °C
Gas Flow Rate
0.2 l/m for TMX, for CO and Nitrox almost any flow rate is possible
Oxygen Sensor
R22S or DVO2
Charging
USB-C
Display
HR-TFT display
App
Models that work with the Divesoft App allow extended data display and management.
GasBlend - advanced Best mix manager, blending tools.
Label printing through any printer connected to the phone.
Charging via USB-C.
